500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Washing Filling Capping Equipment / Plant / Machine / System / Line

Name: 500ml 1L 2L PET Drinking Water 3 In 1 Monoblock Washing Filling Capping Equipment Plant Machine System Line
Brand: FillPack
Price: 20000 USD

Quality 500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Washing Filling Capping Equipment / Plant / Machine / System / Line wholesale

Brand Name : FillPack

Model Number : CGF40-40-10

Certification : CE / ISO9001 - 2008

Place of Origin : Zhangjiagang, China

MOQ : 1 set

Price : 20000-40000USD

Payment Terms : L/C, D/A, D/P, T/T, , MoneyGram

Supply Ability : 15 Sets Per Months

Delivery Time : 30 Working Days After Deposit

Packaging Details : Wooden Case Package

Control : PLC+ Touch Screen

Dimension(L*W*H) : 2450*2100*2400 mm

Driven Type : Electric 380V 50Hz

Type : Filling Machine

Contact Now

Decription of CGF40-40-10 Pure drinking water PET bottle 3 in 1 bottling line

>>>Characteristics:
★The most advanced technology from Japan and Germany is employed in the design. The gravity fixed liquid surface filling is used.The filling is fast, the amount of liquid is accurately controlled and the dropping and leakage are avoided.
★Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180~ along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.

★1.monoblock washing filling capping machine Except the down framework, the transmission parts and some parts that must be made of special materials. Other spare parts are made of stainless steel 304.
★2.The motivation is derived from the driven system in the framework passed by gear.

★1) monoblock washing filling capping machine Adopted Germanyanti-corrosion non-maintaining bearing that can reduce the pollution of filling to the environment.
★2) The liquid supply adopts the automatic pneumatic valve magnetic liquid-level switch to control the liquid tank automatically.

This monoblock washing filling capping machine is the highest degree of accuracy of 3 in 1 machine, it is important for the machine to run stably and the product quality.
★ There are aseptic nozzles between the transition poking wheel and filling parts to rinse the product rested in the bottleneck screw parts.

Parameters
Model	CGF40-40-10
Capacity(B/H)	20000
Bottle size	Neck :φ50-100mm:Height:150-320mm
Water pressure	0.18-0.25Mpa
Water consumption(kg/h)	1000
Washing station	18
Loading-Dripping-discharge station	2-2-2
Filling precision	<+1MM
Air pressure	0.5Mpa
Air consumption (m³/min)	0.3
Power(kw)	7
Weight(kg)	4000
Dimension(LWH)(mm)	386031502400 mm

500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Washing Filling Capping Equipment / Plant / Machine / System / Line

Our Washing-filling-capping machines (3-in-1 and Linear type)
3in1(0-2L bottle)	Capacity(bottle per hour)	3in1(3-10L bottle)	Capacity	Linear type	Capacity
CGF8-8-3	2000-3000BPH	CGF8-8-3B	0-1000	CGF4-4-1	500BPH
CGF12-12-4	3000-4000BPH	CGF12-12-4B	0-1500	CGF6-6-1	750BPH
CGF18-18-6	6000-7000BPH	CGF18-18-6B	0-2500	CGF8-8-1	1000BPH
CGF24-24-8	11000-12000BPH	CGF24-24-8B	0-3500	CGF10-10-1	1500BPH
CGF32-32-10	14000-15000BPH	CGF32-32-10B	0-5000	CGF12-12-1	2000BPH
CGF40-40-10	19000-20000BPH
CGF50-50-12	23000-24000BPH

More capacities if you need, we can also customize that for you. please check them on our website or contact the sales consultant directly. Please find the contact information at contact us.
